Clocking
Table 60. e300 Core PLL configuration (continued)
RCWL[COREPLL]
core_clk : csb_clk Ratio
VCO Divider
0-1
2-5
6
01
10
11
0011
0011
0011
0
0
0
3:1
3:1
3:1
÷ 4
÷ 8
÷ 8
NOTE
Core VCO frequency = core frequency × VCO divider. The VCO divider
(RCWL[COREPLL[0:1]]), must be set properly so that the core VCO
frequency is in the range of 400–800 MHz.
23.6
QUICC Engine PLL configuration
The QUICC Engine PLL is controlled by the RCWL[CEPMF] and RCWL[CEPDF] parameters. The
following table shows the multiplication factor encodings for the QUICC Engine PLL.
Table 61. QUICC Engine PLL multiplication factors
RCWL[CEPMF]
00000–00001
00010
00011
00100
00101
00110
00111
01000
01001–11111
RCWL[CEPDF]
0
0
0
0
0
0
0
0
0
QUICC Engine PLL Multiplication Factor = RCWL[CEPMF]/
(1 + RCWL[CEPDF)
Reserved
× 2
× 3
× 4
× 5
× 6
× 7
× 8
Reserved
The RCWL[CEVCOD] denotes the QUICC Engine PLL VCO internal frequency as shown in the
following table.
Table 62. QUICC Engine PLL VCO divider
RCWL[CEVCOD]
00
01
10
11
VCO Divider
2
4
8
Reserved
MPC8309 PowerQUICC II Pro Integrated Communications Processor Family Hardware Specifications, Rev. 3
70
Freescale Semiconductor
